Korg ARP ODYSSEY Module Rev1 - Ex-Demo
This instrument is discontinued

Korg ARP ODYSSEY Module Rev1 - Ex-Demo

Ex-Demo direct from the manufacturer the ARP may have some slight marks or blemishes to the casing however everything will be in full working order and supplied in the original box with a warranty.

FEATURES

• An ARP ODYSSEY in module form that emanates synthesis power from your tabletop
• True analog sound generated by a complete replication of the original ARP Odyssey's circuitry
• Duophonic design with two VCOs
• A rich variety of modulation
• Oscillator sync provides sharp, great-sounding overtones
• Noise generator provides two types of noise: white and pink
• LFO and sample & hold are provided, with switchable routing
• Equipped with all three historic iterations of ARP's low-pass filter circuit
• The DRIVE switch generates extreme and aggressive sounds
• Envelope generator with two types: ADSR and AR
• The original PPC based on a rubber pad has been reproduced
• MIDI IN connector and a USB MIDI port are provided
• Lineup includes the historical Rev1 and Rev3 designs

Synthesis

• 2VCO. The duophonic design allows two different pitches to sound when you play two notes.
• The high degree of pitch stability for which the ARP Odyssey was remarkable in its time has been perfectly reproduced.
• Pitch is variable over a wide range of 20 Hz--2 kHz.
• Pitch modulation and pulse width modulation can be controlled.
• Oscillator sync provides sharp, great-sounding overtones extending into a high range.
• Noise generator provides two noise types: white and pink.
• Powerful LFO can be used as a modulation source for the oscillator or filter, or as a trigger source for sample & hold.
• The distinctive S/H MIXER lets you easily create sample & hold sounds by using the oscillator or noise generator as a source that's triggered by the LFO or keyboard.
• Ring modulator generates metallic sounds with rich overtones.
• The three types of low-pass filter found on different production runs of the original ARP Odyssey are all provided. With a single switch you can select any one of these filters with their differing characteristics: TYPE I (Rev1) is a 12 dB/octave filter with a sharp and punchy sound, TYPE II (Rev2) is a 24 dB/octave filter that's great for thick low sounds, and TYPE III (Rev3) features excellent stability even when the resonance is increased.
• A wide variety of modulation sources such as S/H, LFO, ADSR, and AR can be used to modulate the filter.
• A high-pass filter is provided following the low-pass filter, giving you even broader sound design possibilities.
• A new function, the DRIVE switch generates extreme and aggressive sounds.
• VCA GAIN slider leaves the note sustaining. Ideal for sound design.
• Envelope generator with two types: ADSR and AR. This can be used not only for the VCA but also to modulate the filter or oscillator.

Control

• The original PPC (Proportional Pitch Control) based on a rubber pad has been reproduced. Press the rubber pad with your finger to control pitch bend or vibrato depth in proportion to the pressure.
• A portamento slider and transpose switch are provided. You can also use a switch to select either of the ways in which Rev1 and Rev2/3 of the original ARP Odyssey differ as to whether portamento is applied the moment that you operate the transpose lever.

Connectors

• Two types of audio output jack are provided: 1/4" phone and XLR.
• External audio input jack is provided, allowing you to process sound from an external device.
• Headphone jack with adjustable volume is provided. By connecting the headphone jack to the external audio input jack, you can apply self-feedback to generate powerful sounds.
• CV, GATE, and TRIG jacks are provided, letting you send or receive analog signals to operate the instrument. If you connect the GATE OUT jack to the TRIG IN jack, the EG will not be triggered, allowing you to play legato. - Both 1/4" size and mini-size patch cables are included.
• MIDI IN connector and USB MIDI port are provided, allowing connection to a PC or MIDI device.

Lineup includes the historical Rev1 and Rev3 designs

The ARP ODYSSEY Module lineup includes the best-known Rev3 design with its characteristic black panel and orange silk-screening, as well as the white-paneled Rev1 design that marks this instrument's historic beginning. The unique shape of the slider grips, their smooth operating feel, and the layout of the switches all perfectly reproduce the layout of the original despite the compact module design.

The body, on the other hand, has been redesigned for its new life in module form, featuring a sturdy steel chassis befitting the weighty sounds produced by this instrument throughout its forty-year history.
