Same Range
Korg Pa5X 76£3299.00
Korg Pa5X 61£3149.11
Korg Pa5X 88 Note Weighted Action£3699.01
Korg Pa5X 76 Oriental£4498.99
![](../../../Korg/Keyboards/Pictures/Korg_Pa5X-61_Oriental.png)
Korg Pa5X 61 Oriental
£4299.00 RRP £4299
Out of Stock
Available to Order Estimated delivery Call 01772 722468Free Mainland UK DeliveryNext working day on orders placed before 2pm
Example deposit of £429.90...
- 6 Months 0% APR - £644.85 P/M
- 12 Months 16.9% APR - £350.52 P/M
- 24 Months 16.9% APR - £188.92 P/M
- 36 Months 16.9% APR - £135.48 P/M
- 48 Months 16.9% APR - £109.09 P/M
Other Options
info | specs | videos |
---|
Korg Pa5x 61 key Oriental Version
The Pa5X Oriental comes with an extensive collection of Sounds, Styles, Keyboard Sets and Pads from the worlds of Arabic, Turkish and Persian Music - each created by world-class musicians from those areas.
Highlights
- Over 2,600 sounds (240 oriental sounds and 70 oriental drum kits) 844 factory styles (with 264 oriental styles)
- on-screen virtual keyboard that can be used to select alternative scales
Pa5X Oriental also includes an on-screen virtual keyboard that can be used to select alternative scales or instantly retune individual keys on-the-fly. Multiple scales can play at the same time, with soloists playing with an Arabic scale and the backing tracks continuing to play in Equal tuning. An alternative scale tuning can be saved into each Keyboard Set and applied to any Style Sound.
The Korg Pa5X is the new flagship in the KORG Professional Arranger lineup, redefining an arranger keyboard. It replaces the immensely popular Korg PA4X. Completely redesigned with a state-of-the-art sound engine and a streamlined color-driven user interface, Pa5X produces a stunningly rich and unique sonic experience that inspires you to create and perform!. The Korg PA5x is the first top of the range keyboard to offer an 88 note fully weighted version
![](Pictures/Pa5X-Screen.jpg)
Pa5X comes packed with thousands of inspiring Sounds and loads of fresh Styles, all instantly accessible through the large, detailed screen . A completely new front panel featuring an assignable Pad Matrix and Mixer section, multicolored LED buttons, and a huge tilt-able touchscreen puts you in control of your music making experience at all times.The Korg Pa5X excels both as a live performance instrument and as a powerful creative tool in the studio, allowing you to find your ideal sound no matter where your music takes you.
Main Features
Premium Quality and Elegant Design
Modern and Streamlined User Interface
Stunningly rich sound-engine: EDS-XP
Real-time controllers
Advanced Chord Recognition System and Full Library of Chord Sequences
Smooth Transitions between Sounds, Styles and Songs
Cutting-edge Dual Crossfading Players /p>
Creating Styles and Songs
The SongBook: A Music Library Always With You
A Complete Sound Library
Intuitive Mixer Section with Extensive Effects Processing
Dedicated Microphone and Guitar Inputs with Effects Processing
MIDI, USB, HDMI, Audio In and Out, Pedal Connectors
Standard File Formats
Optional high-quality accessories
In keeping with Korg top of the range Keyboards The Pa5X has Premium Quality and Elegantly Designed cabinet
The Korg Pa5X was designed with elegance and durability in mind, featuring a sturdy aluminum body and genuine wooden side-panels for a luxury appearance. All of the keybeds on Pa5X provide an authentic feel and full control of expression for any playing situation. The 88-key weighted action has a realistic piano-like touch while the 76- and 61-key versions feature lighter touch semi-weighted keys. All the keybeds include aftertouch control for added expressivity.
Korg Pa5X - Modern and Streamlined User Interface
![](Pictures/Pa5X-Style--Buttons.jpg)
At the center of Pa5X is a large 8"tiltable touch screen that displays a completely redesigned layout. This makes all the sounds and features of Pa5X easily accessible to home and studio musicians as well as live performers. The colors in the display are carefully matched to the ones used in the LED programmable buttons on the control panel. This color driven interface allows you to easily navigate Pa5X, adding color to your music!
The Korg Pa5X Powerful EDS-XP Sound Engine for Rich and Inspiring Sounds - You really have to try the Pa5X to appreciate how good it sounds and feels
KORG Professional Arrangers have set the industry standard for powerful musical expression, featuring sound engines that inspire musicians to create and perform. Pa5X introduces the EDS-XP (Enhanced Definition Synthesis - Expanded) sound-engine, which builds upon the technology used in Pa4X with advanced hardware and a powerful new operating system, taking sounds on Pa5X to a new level. The 24 stereo Oscillators and 160 voices of polyphony power thousands of high-quality sounds, covering a wide range of musical instruments and genres. The EDS-XP sound engine also introduces new cutting-edge features such as Round-Robin drum and percussion performance, Smooth Sound Transition, Sound-Controller 3 functionality and much more. The Korg Pa5X sounds amazing with incredible expression through the keys
![](Pictures/Pa5X-Strip-Display.jpg)
Realtime Controllers on the Korg Pa5X
Pa5X features a fully programmable control section with 9 buttons and 9 sliders. You can assign any function to it, from mixer volume to drawbar settings, from microphone mute to bass inversion, to lyrics scroll commands and more. The assigned function is shown by an auxiliary strip display so that you always know what you have under your fingertips - even if you are on a different page to the main display.
Numerous assignable controllers are available for expressive real time playing and Korg's DNC (Defined Nuance Control) which supplies so much of the detail in the sound of musical instruments. Faders, switches, real and virtual matrices of real time controls, the joystick, and the ribbon controller can be assigned to modulate any parameter of the sound. This provides precise control of the most subtle nuances and articulation of the instruments you are playing on the Pa5x.
![](Pictures/Pa5X-Joystick.jpg)
The Korg Pa5X has Advanced Chord Recognition System and Full Library of Chord Sequences
Pa5X's chord recognition system is the most sophisticated around, featuring an Expert mode that is crafted around the playing styles of the best modern jazz pianists. This chord recognition system can be as simple or advanced as desired, even allowing you to trigger chords with a single finger!
With automatic harmonization, a chord sequencer, and a sophisticated chord recognition engine, Pa5X gives you the tools to create rich musical arrangements no matter what the genre of music.
The Korg Pa5x has Smooth Transitions between Sounds, Styles and Songs - It feels more natural when changing sounds
The Korg Pa5X adds Smooth Sound Transition (SST) technology, allowing for seamless transitions between Sounds, Styles and Songs without any interruption. When you select a different element, the sound, effects and sequences will continue to play, fading away naturally until you are ready for the next sequence or note to begin, making for an uninterrupted and realistic performance.
Another new feature is the Cutting-edge Dual Crossfading Players
Pa5x can play two Styles, MIDI files, or MP3 files simultaneously and in any combination, made possible by the dual onboard Players*. These two Players can be mixed with a handy crossfader, or can be used to play a song while another one is waiting to start. All the while, Pa5X's sound engine delivers the power, effects processing, and polyphony to make these transitions happen seamlessly.
*KORG's exclusive XDS Crossfade Dual Sequencer/Player
![](Pictures/Pa5X-Lyrics.jpg)
Lyrics, Chords, Score and Marker can be clearly shown on the large internal display of Pa5X, or even on an external display when connected via the built-in HDMI port. A wide variety of Lyrics formats are supported, and you can even automatically generate a score from a MIDI Song. Markers allow for quick navigation of a song using the Style-Element buttons, allowing you to easily jump back to a passage you wish to repeat while studying, rehearsing, or performing live.
You can create new styles and songs with the Korg Pa5X
You can create your own Styles, and record your own MIDI and MP3 Songs. The included editing features allow for detailed editing of each single recorded event. A sophisticated transposition table adapts the sequences to any chord you may play.
You can record a MIDI Song using a full-featured Sequencer. Even easier, just record what you sing and play (including MP3 Songs) as an MP3 file, and listen to it anywhere you like.
The SongBook: A Music Library Always With You
Songs and Styles can be saved into the onboard SongBook, whose database-like entries are easy to synchronize with external score readers on a tablet. You can therefore use a digital music book to control your Pa5X.
The songs in the music database can be saved into Set Lists, each one dedicated to a show, to a singer or a style of music, for easy handling of all music resources at once during live performances. When choosing a song from the SongBook, you also immediately get the necessary Sounds, the Style, a Song, the effects and even a chord sequence.
![](Pictures/Pa5X-Drawbars.jpg)
A Complete Sound Library - Awesome sounds from Korg
The onboard sounds range from ultra-realistic acoustic instruments, to electric vintage keyboards, to synth classics, with the addition of fantasy sounds and special effects for game, media, video and cinema production. Korg have also included instruments from various ages and world cultures, while also leaving ample room for your own expansions.
The curated selection of acoustic and electric pianos, which includes sounds from Korg's celebrated SV-2 Stage Vintage Piano, is particularly suitable for the hammer action 88 key version. Korg have also included specially selected sounds from their flagship synth workstations: Kronos and Nautilus.
The Pa5X has a new Drawbar Organ section which proudly boasts realistic control surface that can rely on the physical sliders and buttons on the main panel of Pa5X. New effects that are derived from the legendary KORG CX-3 Combo Organ are also included. The Pa5X Drawbar organs sound immense
The new Drum Kits were recorded making use of a new technology, based on round robins to increase realism. No two drum hits are equal, resulting in authentic-sounding drum performances. The Korg Pa5X drum patterns sound fabulous and totally natural.
In addition to the huge amount of included sounds, the onboard sampler will help create new Sounds, Drum Kits and Audio Loops. Record your own sounds or import from standard file formats like AIFF, WAV and SF2. The detailed on-board sample editor allows you to fine tune your samples and even transform an audio loop into a percussive kit.
![](Pictures/Pa5X-Mixer.jpg)
Intuitive Mixer Section with Extensive Effects Processing
Sounds on Pa5X are processed by an elaborate chain of professional studio quality effects, with up to 10 Insert FX, 3 Master FX and 1 Finalizer for each of the two Players. The Keyboard Sets can use up to 3 Insert and 3 Master FX.
Final mastering effects are applied as the last step on the audio outputs of Pa5X,resulting in a polished sound which is blended and produced. This is a result of KORG's long term cooperation with Waves AudioŽ,the world reference in studio mastering effects. This is something that we noticed as soon as we plugged into monitor speakers, Everything is full fat and rich in tone.
Dedicated Microphone and Guitar Inputs with Effects Processing
A microphone and a guitar can be connected simultaneously to the separate audio inputs of Pa5X. KORG's extensive experience in vocal harmonization technology and guitar effects processing is featured, with each of these inputs having dedicated on-board effects. Guitar player would also benefit from the Korg Pa5x's ability to show chords and easily pre-program chord patterns. As I sit and write this I can hear a Fender Strat through the Pa5X and the effects are stunning.
Korg are proud to have teamed with Shift Audio, a company with 30 years of experience in vocal processing technology. The founders of Shift Audio came from an industry leading company specializing in vocal processing products building on their experience to deliver.
The latest generation of vocal processing algorithms optimized to run on the latest technology used in the Pa5X.
The result is incredible lifelike four-voice harmonies that give you the feeling of a real singing group surrounded by your own music. You will also enjoy the new Auto Pitch feature in the Pa5X delivering performance and sound found in a lot of modern music.
![](Pictures/Pa5X-Amp-Models.jpg)
The separate guitar input is completely independent and even has its own gain control. Guitar effects include vintage pedal and amplifier simulators to enhance your guitar sound and performance. There are many predefined guitar-presets of up to 4 insert-effects provided, and it is also easy to create and save user effects presets. These new powerful guitar effects make the live performance of your guitarist much easier, as all the effects and effect-settings are handled by the Korg Pa5X.
One vocal and one guitar-preset can be assigned to each SongBook entry which makes for an easy and fast musical performance.
MIDI, USB, HDMI, Audio In and Out, Pedal Connectors
![](Pictures/Pa5X--Connections.jpg)
The Korg Pa5X offers a plethora of audio, control and storage connections. You can use MIDI and USB for controllers or storage devices, HDMI for an external display, the XLR, jack and minijack audio connectors for other keyboards, condenser and dynamic microphones, guitars and bass guitars, smartphones and tablets, or to connect your instrument to powered speakers or PA systems via the balanced outs. Four separate line outs are available to handle sounds separately.
![](Pictures/Korg-Pa5X-Audio-Out.jpg)
Three pedal inputs allow for connecting your preferred damper pedal (with half-pedal support), footswitch, volume and expression pedals. You can use the ones you already own, or choose from our range of optional accessories.
Korg Pa5XStandard File Formats
The use of standard file formats, such as MIDI or MP3 for songs, WAV, AIFF and SF2 for samples, opens up a world of possibilities when exchanging files. The MIDI and USB ports allow Pa5X to connect with any external storage device, personal computer, smartphone, tablet or external controller. The HDMI connector is compatible with many modern monitors and club video circuits, allowing Pa5X to serve as the center of your studio or stage setup!
![](Pictures/Korg-Pa5X-Matrix.jpg)
Optional High-Quality Accessories
The optional modern and stylish ST-SV1-BK stand keeps Pa5X sturdy while performing on stage and thanks to an elegant design, it can also function as a stylish piece of furniture when setup in your home.
Pa5X is compatible with the KORG PaAS Amplification System, a speaker system which has been specifically designed to easily connect directly to Pa5X without cables. This allows you to listen with the best audio quality, even at the lowest volume levels for rehearsing at night. Simply put it in place and play!
Korg Pa5X Oriental Specifications
Keyboard
Pa5X 61: 61 keys (C2 - C7) Semi-weighted keys with Aftertouch
Pa5X 76: 76 keys (E1 - G7) Semi-weighted keys with Aftertouch
Pa5X 88: 88 keys (A0 - C8) Hammer action with Aftertouch
Case
Aluminum case with wooden side panels
Operating System
Upgradable Operating System
Sound Generator
EDS-XP (Enhanced Definition Synthesis-Expanded)
Multimode filters with resonance, 3-band EQ for each track
Polyphony
160 Voices, 160 Oscillators
Effects
Keyboard Tracks:3 Insert Effect; 3 Master Effects
Style/Song:10 Insert Effects; 3 Master Effects
Master EQ and Finalizer for Songs and Styles
Final Mastering Effects:Waves | MaxxAudio Suite
Mic Processor Technology by Shift Audio
Mic Setup: Compressor, EQ, Gate
Four-part Harmonizer, Doubler, Filter, Modulation, Delay, Reverb, AutoPitch
Guitar Processor
Guitar rack (4 effect-slots) with stompbox and amp simulation
Sounds / Drum Kits
Factory: More than 2,200 Factory Sounds
Five multilayer Stereo Acoustic Pianos with Damper/Body Resonance, GM/XG Sound Sets, more than 130 Drum Kits including Ambient Drums and Round Robin-based Drum Kits
User Area: 768 Sounds, 384 Drum Kits
Digital Drawbars: 9 Footages, Percussion, Key On/Off, Leakage, Vibrato/Chorus, Rotary Speaker with Amp Simulator
Natural Ambience Drum Sounds, Round Robin features
Defined Nuance Control (DNC) Technology
Quick and Full Sound Editing, Drum Family and Full Drum Kit Editing
Sampling
User PCM Sample memory: 4 GB of data, equivalent to 8 GB linear when compressed
Loads KORG, WAV, AIFF and SoundFont formats
Saves KORG, WAV and AIFF formats
Full Edit, Time Slice, Sampling features
Keyboard Sets
Factory: More than 500 Factory Keyboard Sets, freely programmable
Combines four Keyboard Sounds, plus Effects and settings
Library accessible from front-panel buttons
"My Setting" special Keyboard Set
Players
Patented XDS Crossfade Dual Player with X-Fader Balance control
Crossfading between Songs and/or Styles
Styles
Factory: More than 600 Factory Styles, freely programmable
Eight Style Tracks, 4 Keyboard Sets and 4 Pads per Style; Programmable Sounds, Effects and Style parameters
Guitar Mode 2, Parallel and Fixed NTT (Note Transposition Table)
Style Record and Event Edit
Style Elements: 3 Intros, 4 Variations, 4 Fills, 1 Break, 3 Endings
Style Controls: Play/Stop, Synchro Start, Synchro Stop, Tap Tempo/Reset, Auto Fill, Memory, Bass Inversion, Manual Bass, Bass & Lower Backing, Drum & Bass, Individual Style Tracks Mute, Style to Keyboard Set Set
Chord Sequencer
Factory: More than 200 Chord Sequences
Chord Sequence Recorder/Player
Chord Sequences can be saved to Style and SongBook Entries
Songs
Patented XDS Crossfade Dual Player with X-Fader Balance control
Supported formats: MID, KAR, MP3 + Lyrics, MP3+G
Lyrics, Score, and Chord data can be displayed on screen, or on external video monitor
Markers with Add, Delete, Edit, Loop and AutoScroll functions
Jukebox function
Full-featured, 16-track Sequencer, Song Edit
MP3 Player / Recorder
Double MP3 Player and MP3 Recorder
Records MP3 files, including Styles, MIDI Songs, MP3 Songs, Keyboard Sounds, Pads, Matrix, Microphone, Guitar, Effects
Transpose (+6/-5 semitones), Tempo Change (30%)
Vocal Remover
SongBook
Fully programmable music database based on Styles, MIDI Songs (MID and KAR files), MP3 Songs with Artist and Genre tags
Filtering and sorting options
User definable Set Lists
Pads
Factory: More than 400 Pads
Four Assignable Pads + Stop Buttons
Pad Record function
Control Section
9 Assignable Sliders, 9 Assignable Buttons, Strip Display; 4 Preset + 1 User settings
Matrix Section
16 Matrix Pads, 4 Preset buttons
Style/Song Controls
Play/Stop, Go To Start, Style Select, Song Select, Xfader, Tempo +/-, Tempo Lock, Tap Tempo/Reset, Synchro Start, Synchro Stop, Fade In/Out, Chord Scan (Lower, Upper), Chord Sequence, Memory, AutoFill
General Controls
Master Volume, Octave Transpose, Master Transpose, Dial, Up/+, Down/-, Joystick (Pitch + Modulation), Ribbon, 3 Assignable Switches, Search, Shift, Keyboard Sounds On/Off, Split, Ensemble, Rec/Edit, Menu, Exit
Scale Controls
On-screen Quarter Tone and Arabic Scale, memorized in the Keyboard Sets; Presets assignable to any button or footswitch
Control Inputs
Damper Pedal; supports half-pedaling with the optional KORG DS-1H pedal
2 Assignable Pedal/Footswitch
Audio Inputs
Mic: Mono with Gain control and Phantom Power (Combo XLR, balanced)
Guitar: Mono with Gain control (1/4" jack, unbalanced)
Line 1: Left/Right (1/4" jacks, balanced)
Line 2: Stereo (1/8" mini-jack, unbalanced)
Audio Outputs
Line: Main Left/Right, Separate Outs 1/2/3/4 (1/4" jacks, balanced)
Headphones (1/4" jack)
Video Output
HDMI connector
MIDI
IN, OUT, THRU standard MIDI connectors
USB to MIDI, through the USB Device port
16 User-definable MIDI Presets
USB
Type A (Host 3.0, for storage devices and controllers): 1 front, 2 rear
Type B (Device 2.0, for personal computers and tablets): 1 rear
Storage
Internal Drive: 1 GB
Micro SD Card (not included): Rear-panel slot with plastic cover
USB Flash Drive (not included): Can be connected to the USB Host ports
Display
8" Wide capacitive color TouchView TFT display, 800 x 600 resolution
Clock
Internal System Clock
Power Consumption
100-240 Volts, 50/60 Hz
< 0.2 Watt in standby / 20 Watt normal / 45 Watt with PaAS installed
Dimensions (W x D x H) (without music stand, display fully lowered)
Pa5X-88: 1,262.0 x 396.4 x 146.0 mm / 49.68" x 15.60" x 5.74"
Pa5X-76: 1,233.1 x 374.3 x 126.8 mm / 48.54" x 14.73" x 4.99"
Pa5X-61: 1,021.1 x 374.3 x 126.8 mm / 40.20" x 14.73" x 4.99"
PaAS (optional): 980 x 180 x 140 mm / 38.58" x 7.08" x 5.51"
Weight
Pa5X-88: 20.1 kg / 44.31 lbs
Pa5X-76: 17.4 kg / 38.36 lbs
Pa5X-61: 15.1 kg / 33.29 lbs
PaAS (optional): 5.70 kg / 12.56 lbs
Accessories
AC Power Cable, Music Stand, Quick Guide manual
Options
PaAS Amplification System
ST-SV1-BK Keyboard Stand
EXP-2 Foot Controller
XVP-20 Expression/Volume Pedal
DS-1H Damper Pedal (supports half-pedaling)
PS-1 Pedal Switch
PS-3 Pedal Switch
VOX V860 Volume Pedal
* Appearance and specifications are subject to change without notice.
** All product, company,and standard names are trademarks or registered trademarks of their respective holders.
